Features:
● For Chemical and Industrial Applications
● ISO 5211 Mounting Pad
● Blow-Out-Proof Stem
● High-Cycle, Live-Loaded Stem Packing
● Investment Casting Body and Cap in Stainless or Carbon Steel to NACE MR01.75
● Basic Construction: ANSI B16.34
● Shell and Seat tested to ANSI B16.34 and API 598
● Length to ANSI B16.10
● Connection to ANSI B16.5
● Temperature Range (RTFE): -20ﾟF ~ 420ﾟF
● Maximum Pressure(RTFE): ANSI 150: 275 PSI WOG
● ANSI 300:720 PSI WOG
● End type: ANSI 150, ANSI 300 on request
● Option: Anti-Static Device
